Rigorous Testing & Commissioning

Noman Elevators delivers Rigorous Testing & Commissioning with Sharif Mill precision.

Testing ensures every elevator achieves 95% uptime from Day 1. Our 17 Raheem Road technicians execute comprehensive validation before handover, meeting EN81-20 standards and Pakistani building codes.

Mechanical Performance Tests

Pre-Test Controller Setup

Elevator placed in normal automatic operation (not inspection mode).CAN-bus controller diagnostics confirm zero faults. All safety chains verified closed (doors, limits, buffers). VVVF drive parameters loaded: 1.75m/s max speed, jerk ≤1.5m/s³.

Cycle Initiation (Cycle 1-25)

Technician registers car calls to all floors simultaneously. Elevator executes full journey: lowest floor → highest floor → repeat. Digital logger records: speed profile, acceleration curves, settling times. Each floor stop verifies ±5mm leveling accuracy.

Door Operation Validation (Cycles 26-50)

Door open/close timing measured against EN81-20 limits: Open time: ≤12 seconds (450kg cab) Close time: ≤10 seconds Nudging operation tested (3-second pressure override). Photoelectric sensors confirmed unobstructed across 100 door cycles.

Ride Comfort Analysis (Cycles 51-75)

Vibration monitoring (<0.1g RMS) using triaxial accelerometer: Motor room vibration envelope Cab floor vibration signature Guide shoe/shoe bracket interface Jerk measurement peaks never exceed 1.5m/s³ during acceleration/deceleration.

Emergency Stop Verification (Cycles 76-100)

Random floor emergency stop button activation during travel: Response time ≤1.5 seconds to full stop Re-leveling accuracy ±10mm after reset 5 consecutive stops per floor, staggered randomly Brake holding force confirmed across full speed range.

Data Analysis & Reporting

Controller downloads 100-cycle performance log: 15,000+ data points analyzed (speed, jerk, leveling, vibration) Pass criteria: 98% cycles within specs CAN-bus fault log reviewed (must show zero repeat faults) Digital certificate generated for client handover.

Noman Elevators: Precision Elevator Construction Excellence

Elevator construction requires engineering precision beyond ordinary building work. Noman Elevators delivers turnkey installations from 17 Raheem Road that achieve 95% uptime through Sharif Mill-certified processes.

Advanced Engineering Planning

Shaft & Pit Engineering

Laser-precise measurements create 1500x1500mm shafts, 1400mm pits, T-9 rail alignments (1:1000 tolerance). VVVF motor layouts optimize 20kW power distribution. SS304 cab designs maximize light/noise isolation.

Load & Speed Optimization

450kg residential (1.75m/s), 1000kg commercial (1.5m/s), 1600kg hospital (1.0m/s) - each capacity engineered for Lahore high-rise demands. CAN-bus controls enable duplex/triplex group operation.

Code Compliance Matrix

EN81-20 safety, Pakistani Building Code seismic, Phase I/II fire service - every drawing stamped by Sharif Mill engineers before fabrication begins.

Quality Control & Installation Oversight

Noman Elevators maintains absolute precision throughout construction with multi-layer verification systems.

20+ Years Misri Shah Mastery

Proven Infrastructure
17 Raheem Road warehouse stocks T-9 rails, VVVF motors, SS304 panels – immediate staging eliminates 8-week lead times competitors face. 100+ Shalimar installations prove execution excellence.

Certified Workforce
Sharif Mill technicians trained on DJ-A laser alignment, FAT testing protocols, 125% overload validation. 24-month warranty backed by 2-hour emergency response SLA.

Technical Authority
Aircraft-grade T-9 rails (5mm thick), permanent magnet VVVF motors (30% energy savings), ARD rescue systems (2hr UPS) – materials selected for Lahore’s humid/seismic environment.

Engineering Advantages

By ordering the installation services from us, we can be sure of the quality of materials and installation.

24/7 support for regular customers

All masters are qualified and have diplomas

We use only the highest quality materials

Wide range of interiors designs collection

Extended warranty for work and all products

Free consultation and delivery of materials

Portfolio: Shalimar Success Stories

Tower Residency (2025)
7-stop passenger lift, 1000kg, 1.75m/s VVVF, glass SS304 cab – handed over Week 11.

Misri Shah Hospital
1600kg service lift, ARD rescue, Phase II fire service – 125% overload passed Week 10.

Gulberg Factory Duplex
2x1000kg cargo lifts, 2m freight doors – synchronized commissioning Week 12.

Frequently Asked Questions

What's included in 8-12 week timeline?

Laser survey → engineering drawings → FAT-tested delivery → rail alignment → 100-cycle testing → client training.

Hospital lift requirements?

1600kg stretcher cabs (1100x2100mm), ARD power failure rescue, 0.63m/s smooth operation, Phase I/II fire recall.

Can you modify existing buildings?

Yes - machine room conversions, shaft enlargements (1500x1500mm min), pit deepening (1400mm).

Warranty coverage details?

24-months full coverage, 95% uptime guarantee, 2-hour Misri Shah response, quarterly inspections included.

VVVF vs hydraulic comparison?

VVVF = 30% energy savings, 1.75m/s speed, smooth ride. Hydraulic = low-rise freight, slower (0.63m/s).
